SGP36-36BL: dc brushless planetary gear motor

Description

Model:SGP36-36BL dc brushless planetary gear motor
1.Diameter: 36mm
2.Voltage: 24V
3.Input speed: 4000rpm
4.Reduction ratio: 1/3.7,1/5.2,1/14,1/19,1/27...
5.Output speed: 14~755rpm
6.Rated torque: 1~30Kg.cm
7.Built-out drive (8 wires),built-in drive (5 wires)
8.Specs can be custmized for you

Applications

1.Pump

2.Medical system

3.Robotic

4.Home appliances
